Basic Info.
Model NO. | PA-700FS-IQ |
Air Flow | 700m3/h |
Power | 600W |
Air Pressure | 3800PA |
CE | CE |
Filtration Efficiency | ≥99.997% |
Noise | ≤65dBA |
Voltage | 110V/60Hz & 220V/50Hz |
Product | Laser Cutting Dust Collector |
Key Words | Laser Cutting Dust Collector |
After-sales Service Provided | Overseas third-party support available |
Transport Package | Pack in a Strong Plywood Box |
Specification | 475*581*1057mm |
Trademark | Pure Air |
Origin | China |
HS Code | 8421392990 |
Production Capacity | 1000PC/Month |
Product Description
Pure-Air PA-700FS-IQ China Supplier Hot Sale Industrial Vacuum Cleaner Price With 700m3/h Air Flow And Warming System
Product DescriptionProduct Application:Our PURE-AIR Laser Fume Extractor suitable for air purification, fume filtration and dust collection for CO2 Laser processing non-metal and small fiber laser marking metal. We have full machine range from small power unit to bigger one, from PA-300TS to PA-2400FS,max air flow from 300m3/h to 2400m3/h. This is enough to cover the application range for major kinds of CO2 laser machine.
Product Function:
1) Air Purification, dust collection and fume filtration for different industry, suitable for single workstation;
2) This range including Air flow is from 300m3/h to 24000m3/h, blower capacity is from 200W to 2.2KW;
3) 4 layers filtration to ensure filtrate harmful material of the fumes completely, to achieve room air quality standard, protect environment and people's health, It included below 4 layer filters to make sure the high air purficiation performance:
a) 1st layer is G3 Primary filter for remove big and heavy particles/smoke/dust(>=5Micron)
b) 2nd layer is F8 medium efficiency bag filter for remove big particles/smoke/dust(>=1Mircron).
c) 3rd layer is H13 class HEPA filter to remove small particles (>=0.01Mircron) and smoke.
d) 4th layer is Activated carbon filter to adsorb smells and toxic gas.
Customer Review
4. Specification Sheet:
Equipment Data | ||
Item | Technical Data | Remark |
Fume & dust inlet | 150mm or 75mm | Single or Double fume inlets, include one or two set fume extract tubes |
Fresh air outlet | 150mm | window-shades holes |
Machine weight | 85KG (N.W.) 125KG(G.W) | Machine with all elements |
Dimension | 581*475*1057mm | Machine size |
Package dimension | 640*595*1300mm | Packed by plywood crate |
Blower Technical Data | ||
Item | Technical Data | Remark |
Running period | more than 30,000h | One year guarantee |
Max. air flow | 700m³/h | / |
Input capacity | 600W blower | Low capacity |
Air pressure | 3800pa | High pressure |
Running sound | ≤65dBA | / |
Input power | 110/220V, 50/60Hz | International standard |
Filter Elements Data | ||
Item | Technical Data | Remark |
F5 Primary filter PA700-01 | F5 Primary filter | For remove big and heavy particles/smoke/dust(>=5 Micron) |
Pre-filter PA700-02 | F8 medium efficiency bag filter | F8 medium efficiency filter for remove big particles/smoke/dust(>=1 Mircron). |
Main-filter PA700-03 | H13 class HEPA filter | Filter can remove 99.997% of all particles above 0.3 microns and 95% down to 0.01 micron. |
Gas-filter PA700-04 | Activated carbon filter | Chemical molecular, Oxidant & Active carbon adsorb noxious gas. |
Average filtration rate | ≥99.7% | It will be a little fluctuation according to different materials. |
5. Product Description
Pure-Air PA-700FS-IQ laser fume extractor suitable for fume filtration and dust collection for 900*600mm CO2 Laser cutting/engraving non-metal like acrylic/plastic/paper/rubber, etc
PA-700FS-IQ air flow is 700m3/h, blower capacity is 600W, air flow can be adjustable both by key switch and remote control, it has LCD display to show air pressure and air flow. It also has warning system to remind customer to replace filters once filters blocked. And it has the function that can work with laser machine synchronously.
This model has very good performance for filtrate fumes and collect dust, adsrob strong smell for laser processing acrylic/wood/rubber/paper and plastic. PA-700FS-IQ has below below 4 layer filters to make sure the high air purficiation performance.
1) 1st layer is G3 Primary filter for remove big and heavy particles/smoke/dust(>=5Micron)
2) 2nd layer is F8 medium efficiency filter for remove big particles/smoke/dust(>=1Mircron).
3) 3rd layer is H13 class HEPA filter to remove small particles (>=0.01Mircron) and smoke.
4) 4th layer is Activated carbon filter to adsorb smells and toxic gas.
6.More Products
7.Exhibition
8.Why Choose Us
9.Packaging & Shipping
10.FAQ
Q: Are you trading company or factory?
A: We are professional factory for making fume extractor, dust collector;
Q: Do you only sell products in name of your own brand PURE-AIR?
A: Except sell in name of our brand, we can also make OEM products and show customer's LOGO;
Q: How long is your delivery time?
A: Normally it is 2-10 days for standard products, for customized products takes 10-20days;
Q: How about your package?
A: We pack goods firstly with stretch film and then pack in strong plywood box, plywood box no need do fumigation.
Q: How long is the quality guarantee of your fume extractor?
A: We can offer 1 year quality guarantee and life-long maintenance of our machine after the warranty period.
